The device combines a unique plasma sterilization technology using hydrogen peroxide and a low temperature regime that gently affects and protects medical products from wear. Support for a wide range of materials makes CADUCEUS REFINE 190 ready to work, including with biopolymer implants, 3D printed surgical instruments and complex endoscopic systems. The capacious sterilization compartment with a volume of 192 liters allows you to effectively process a large number of instruments and complex medical equipment in the shortest possible time.
High quality sterilization is achieved thanks to a unique double plasma phase, which guaranteedly destroys bacteria, viruses and microbial spores, reaching a guaranteed sterility level of 10⁻⁶. The touch display, intelligent algorithms for monitoring the state of the process and a reliable design make the operation of the CADUCEUS REFINE 190 plasma sterilizer as convenient as possible, and the integrated system for monitoring and recording work helps to keep strict records of all procedures, ensuring transparency and compliance with sanitary standards.
Specifications
| Chamber volume | 192 L |
| Recommended load | 155 L |
| Chamber dimensions (L×W×H) | 820 × 510 × 460 mm |
| Overall dimensions (L×W×H) | 1105 × 790 × 1765 mm |
| Operating temperature | 50°C |
| Sterilization cycle | ≈1 hour |
| Sterilizing agent | 60% H₂O₂ |
| Control | Foot pedal |
| Noise level | <70 dB |
| Power supply | 220 V, 50 Hz, 4.8 kVA |
Documents
You can request additional information about the equipment, as well as find out the cost and place an order by writing to us at info@westmedgroup.ru
